Product Introduction

U-AL Bimetallic Cable Lug DTL-8S

1.The solid palm eliminates the ingress of moisture.
2.The barrels are chemically treated to reduce contact resistance and corrosion
refilled with jointing compound
3.Friction welded

Item No.	Dimensions(mm)
	Ø	B	P	L	L1	b
DTL-8S-16	5.5	8	30	82	40	16
DTL-8S-25	6.5	8	30	82	40	16
DTL-8S-35	8	8	30	82	40	16
DTL-8S-70	11	12	45	97	40	20
DTL-8S-95	12.5	12	45	97	40	20
DTL-8S-120	13.7	14	55	125	55	25
DTL-8S-150	15.5	14	55	125	55	25
DTL-8S-185	17	14	55	125	55	32
DTL-8S-240	19.5	14	55	125	55	32
DTL-8S-300	23.5	18	46	131	65	34

DTL-8S SERIES BIMETALLIC LUG ARE SUITABLE FOR TRANSITION CONNECTION OF THE CIRCULAR ALUMINUM WIRES, HEMICYCLES-SECTOR ALUMINUM WIRES, POWER SUPPLY CABLES IN THE DISTRIBUTION EQUIPMENT AND COPPER TERMINALS OF THE ELECTRICAL EQUIPMENT THEY ARE MADE FROM CU 99.9% PURITY AND AL 99.5 PURITY.
