1.1 suspension clamp are designed to suspend self supporting LV-ABC cable on the poles with the insulated neutral messenger.

Material used is UV Resistant Glass Filled Nylon, advantages the product has that because it is made of plastic it is fully Insulated and also does not have any loose parts, cable can be gripped by adjustment of push type lever.

Introduction to suspension clamp:

The suspension clamp is a connecting device that suspends optical cable from the tower of transmission line.The cable clip can reduce the static stress of the cable at the suspension point, improve the anti-vibration ability of the cable, and suppress the dynamic stress of the wind vibration.It can also ensure that the bending of the cable does not exceed the allowable value, so that the cable does not produce bending stress.Because the cable is installed after the clip, will not produce a variety of harmful stress concentration, so the optical fiber in the cable will not produce additional loss.

Composition of suspension clamp:

1. Aluminum splint: made of corrosion resistant aluminum alloy by pressure casting, the aluminum alloy chemical performance is stable, atmospheric corrosion resistance is good, and has good mechanical properties.

Two, rubber fixture: composed of high quality rubber and central strengthening parts, with ozone resistance, chemical resistance, climate aging resistance, high and low temperature performance, and high strength and elasticity, small compression deformation.

3. Bolts, spring pads, flat pads and nuts: hot-dip galvanized standard parts.

4. Closed pin: electric power standard parts.

5. wire protection pre-twisted wire: according to the predetermined mechanical properties and chemical composition of customized aluminum alloy wire, with high tensile strength, hardness and good elasticity and strong antirust ability, can be used in harsh climate environment for a long time.

6. The outer pre-stranded wire: same as the pre-stranded wire of the protective wire.

7. Connection fittings: U-shaped hanging ring, U-shaped screw, UB hanging plate and ZH hanging ring are all standard parts of power.

Instructions:

1. Single overhanging wire clip can be used for connection between optical cable and linear tower or the pole tower with Angle/elevation ≤25°;Double hanging line clip can be used for large span or large elevation (bending) Angle of the straight line tower.One set for each tower.

2, according to the cable outer diameter and range/comprehensive load selection of suspension clamp.

3. According to the different methods of hanging wires on poles and towers, different connecting fittings can be selected and matched with the hanging wire clip.
