D Stainless Steel Shackle
D Stainless Steel Shackle
D Stainless Steel Shackle
D Stainless Steel Shackle
D Stainless Steel Shackle
D Stainless Steel Shackle
D Stainless Steel Shackle
D Stainless Steel Shackle
D Stainless Steel Shackle
Inquiry Contact us

Like this product? Share with friends:

Product Introduction

D type shackle is mainly used for wiretapping of transmission line and substation, it is made of galvanized steel. The application is used to change the angle and extend the strain gauge.



In addition, the D type anchor shackle can be widely used as the connecting fitting on ADSS/OPGW cable tension clamp/suspension clamp.



item number.

A(mm)

B(mm)

D (mm)

l(mm)

D006

5.7

13

11.9

24.5

D008

7.8

17

16.8

27

D010

9.7

21

19.8

35.5

D012

11.7

24

22.8

41

D014

13.6

28.9

28.1

48.1

D016

15.5

33

30.2

55

D018

17.7

35.5

37.3

61.5

D020

19.5

40

39.3

68

D022

21.9

44.8

44.1

74.8

D025

23.7

55.2

48.3

84.8

D028

27.6

59.3

53.6

100.9

D032

32

66.3

63.5

115
