CUPG parallel groove clamp
CUPG parallel groove clamp
CUPG parallel groove clamp
CUPG parallel groove clamp
CUPG parallel groove clamp
Inquiry Contact us

Like this product? Share with friends:

Product Introduction

CUPG clamp was designed to connect two parallel bare conductors.Conductors can be copper stranded or rods.Material is forged copper for copper to copper connection throughout the conductor range.For tap-off connection of copper conductors.



Structure Feature

1.The clamps have serrated transverse grooves for maximum conductor contact.

2.Stainless bolts and utilize Belleville washers to prevent thermal ratcheting under cyclic loads.



Datas


Type

Conductor Cross-section(mm²）

Bolt

CUPG-A1

CU16-70

1*M8*40

CUPG-A2

CU25-150

1*M8*45

CUPG-B1

CU6-35

2*M6*35

CUPG-B2

CU16-70

2*M8*45

CUPG-B3

CU25-150

2*M8*50

CUPG-B4

CU25-240

2*M10*60

CUPG-B5

CU35-300

2*M10*70

CUPG-C1

CU16-70

3*M8*45

CUPG-C2

CU25-150

3*M8*50

CUPG-C3

CU25-240

3*M10*60

CUPG-C4

CU35-300

3*M10*70
