JY Aluminum Alloy Coupling

Inquiry Contact us

Like this product? Share with friends:

Product Introduction

Medium length splice is used to splice or repair the antenna conductor and ground wire of the power line.

Descriptions:

The splice sleeve is a material for connecting conductors in the electrical industry, a conductor for connecting by pressure using a hydraulic clamp. The outer sleeve is made of aluminum, the inner sleeve is made of hot-dip galvanized steel.

Aluminum alloy splicing sleeve for ACSR generally contains: ACSR splicing sleeves, jumper splicing sleeve, steel strand splicing sleeve, copper splicing sleeve, aluminum splicing sleeve, etc.

Bid:

Medium length splice is used to splice or repair the antenna conductor and ground wire of the power line.

Product Feature:

1.For use with CRIMP tools only

2. For aluminum, ACSR, compact, 5005,6201 and partial tension ACAR (40% rated tension) conductor jumper splicing

3. Aluminum alloy conductor recommendations include 5005 and ACAR, which are the same diameter as the specified ACSR conductor shown below. In addition, compressed (compact) conductor sizes within the same decimal conductor range are recommended.
