Product Introduction

The Clamp body and keepers are made of aluminium alloy

The Cotter-pins are made of stainless steel,

The other parts are  hot-dip galvanized.

(1) The overhanging Angle of the suspension clamp is not less than 25°.

(2) The radius of curvature of the overhanging wire clip shall not be less than 8 times of the diameter of the installed wire.

(3) The gripping force of the suspension wire clip on different wires and the percentage of rated tensile resistance of wires






Catalog No.

Applicable of wire diameter

Main dimensions(mm)

Specified failure load  (kN)

Weight (kg)



L

C

R

H

M

∅



XT-4022

13.2-22

180

20

11

120

16

18

40

3.0

XT-4028

19.6-28

250

20

14

130

16

18

40

3.6

XT-4034

27.4-34

280

20

17

130

16

18

40

4.1

XT-4040

32-40

300

20

20

135

16

18

40

4.9

XT-6028

19.6-28

250

20

14

130

16

18

60

3.6

XT-6034

27.4-34

300

20

17

130

16

18

60

4.1

XT-6040

32-40

300

20

20

135

16

18

60

4.9
