TLG clamp
TLG clamp
TLG clamp
Inquiry Contact us

Like this product? Share with friends:

Product Introduction

TLG type aluminum soldering T-clamp is a bolt for firmly fixing the conductor, in which the clamp and gland (other parts are made of hot-dip galvanized steel) are made of copper and aluminum as the raw material to prevent the fixed conductor from falling off.



Description:
TLG type aluminum soldering T-clamp is a bolt for firmly fixing the conductor, in which the clamp and gland (other parts are hot-dip galvanized steel) are made of copper and aluminum as the raw material to prevent the fixed conductor from falling off. The down conductor terminal is a single plate, suitable for arranging the down conductor. In addition, its estimated service life reaches more than 10 years. Moreover, when it is in the cold and terrible temperature environment, it can always maintain a fairly stable working state without causing any changeable technical parameters.




Type

Applicable conductor cross-sectional area (mm2)

Size (mm)

Weight (kg)

A

Φ

L1

TLG-120~150Q

120~150

50

12.5

65

0.63400
