Cross-arm brackets 5/19 was used for the installation of cross-arms on concrete poles used for low voltage (LV) networks. They hoop on the pole with the use of 2 steel pole bands 20 x 0.7mm. Two cross-arm brackets are required for the fixing of a single cross-arm. These hardware items can be install
Installation of cross arm 5/19 on square concrete poles and of suspension 30/34 on cross-arm.
Installed on poles by two 20 mm bands and on cross arm by 2 bolts 1/12.
Item No. | Designation |
5/19 | Pole steel plate |
Cross-arm brackets 5/19 was used for the installation of cross-arms on concrete poles used for low voltage (LV) networks. They hoop on the pole with the use of 2 steel pole bands 20 x 0.7mm. Two cross-arm brackets are required for the fixing of a single cross-arm. These hardware items can be installed with 2 assembly bolts 1/12.
5/19 cross-arm brackets can also be used to install at 90°
This item was made of iron by casting. The application of castings has a long history. Casting is a process in which metal is smelted into a liquid that meets certain requirements and poured into a mold. After cooling, solidification, and cleaning, a casting with a predetermined shape, size and performance is obtained. Because the casting blank is almost formed, it can achieve the purpose of avoiding machining or a small amount of processing, reducing the cost and reducing the production time to a certain extent. Casting is one of the basic processes of modern device manufacturing industry. Castings are metal molded objects obtained by various casting methods, that is, smelted liquid metal is poured into a pre-prepared mold by pouring, injection, inhalation or other casting methods, and after cooling, after subsequent processing methods such as polishing , The resulting object has a certain shape, size and performance.
