drop wire tension clamp s-type also called ftth drop p-clamp cable clamp is developed to tension and support flat or round fiber optical cable on intermediate routes or last mile connection during outdoor overhead ftth deployment.
Technical specification:
Material | UV resistant plastic & stainless steel |
Model | s-type |
Color | Black or white upon request |
Package Box | 41*33*19 cm |
Product name | drop wire clamp s type |
Flat cable size (w*h) | 2.0*3.0mm or 2.0*5.0 mm, with steel messenger |
MBL,KN | 0.5 |
Length | 135 mm |
Weight | 0.027 kg |
Application:
Used for securing many kinds of cables, such as fiber optic cables.
Used to relieve strain on messenger wire.
Used to support telephone drop wire at span clamps, drive hooks and various drop attachments.
Features:
Good anti-corrosion performance. High strength. Abrasion and wear resistant. Maintenance-free.
Durable. Easy installation. Removable.
Fiber optic drop cable S-type clamp other called Drop Wire P Clamp,
can be used on dead-end fiber network routes.
Its material is PC or ABS plastic. PC has high strength and elasticity coefficient, high impact strength, wide temperature range of use; high transparency and free dyeability; low molding shrinkage, good dimensional stability; good fatigue resistance; good weather resistance; excellent electrical properties.
Acrylonitrile Butadiene Styrene is a thermoplastic polymer structural material with high strength, good toughness, and easy processing and forming. ABS has excellent mechanical properties, excellent impact strength, and can be used at extremely low temperatures: ABS has excellent wear resistance, good dimensional stability, and oil resistance, and can be used for bearings under medium loads and speeds. The creep resistance of ABS is larger than that of PSF and PC, but smaller than that of PA and POM. The bending strength and compressive strength of ABS are the poorest among plastics. The mechanical properties of ABS are greatly affected by temperature.
