RW drop out fuse cutout

Inquiry Contact us

Like this product? Share with friends:

Product Introduction

Type: RW12-11~15

Rated Voltage: 11~15KV

Rated Current: 100A, 200A

Breaking Current: 10KA, 12KA

Impulse Voltage: 110KV

Power frequency withstand voltage:40KV

Leakage distance: 240mm

Weight: 7KGS, 7.5KGS

Dimensions: 420x370x135mm

Type: RW12-11~15/100, RW12-11~15/200

Rated Voltage: 11~15KV

Rated Current: 100A, 200A

Breaking Current: 10KA, 12.5KA

Impulse Voltage: 110KV

Power frequency withstand voltage:45KV

Leakage distance: 372mm

Weight: 5KGS, 5.5KGS

Dimensions: 520x400x140mm

Type: RW12-11~15(F)

Rated Voltage: 11~15KV

Rated Current: 100A, 200A

Breaking Current: 10KA, 12KA

Impulse Voltage: 110KV

Power frequency withstand voltage:40KV

Leakage distance: 372mm

Weight: 8.5KGS, 9KGS

Dimensions: 580x400x150mm

Type: RW12-33~36/100, RW12-33~36/200

Rated Voltage: 33~36KV

Rated Current: 100A, 200A

Breaking Current: 10KA, 12.5KA

Impulse Voltage: 170KV

Power frequency withstand voltage: 70KV

Leakage distance: 660(720)mm

Weight: 14.5KGS, 15KGS

Dimensions: 620x380x170mm

Type: RW12-33~36(F)/100, RW12-33~36(F)/200

Rated Voltage: 33~36KV

Rated Current: 100A, 200A

Breaking Current: 10KA, 12.5KA

Impulse Voltage: 170KV

Power frequency withstand voltage: 70KV

Leakage distance: 660(720)mm

Weight: 15.5KGS, 16KGS

Dimensions: 640x450x170mm
