Stainless steel wing lock cable tie for easy clamping

Stainless steel wing lock cable tie for easy clamping

Inquiry Contact us

Like this product? Share with friends:

Product Introduction

Stainless steel cable ties are generally used where they may be exposed to heat as they can easily withstand higher temperatures than standard cable ties. They also have a higher breaking load and will not deteriorate in harsh conditions. The wing lock version has the advantage of easy and quick handling.

● UV resistance

● High tensile strength

● Acid resistant

● Anti-corrosion protection

● Material: stainless steel.

● Fire resistance class: fireproof.

● Color: Metallic.

● Working temperature: -80℃ to 538℃.

Ratings	Width (mm)	Thickness (mm)	Length (mm)	Max.Package diameter (mm)	Min. Package diameter (mm)	Min. Tensile Strength (N)
304 316	7.9	0.26	200	55	12.7	2220
			300	90
			400	120
			500	150
			600	185
			700	215
			800	250
			300	90
			400	120
			500	150
	10	0.26	600	185	19.05	2800
			700	215
			800	250
			1000	310
			300	90
			400	120
			500	150
	12	0.35	600	185	25.4	3115
			700	215
			800	250
			1000	310
			400	120
			500	150
	15	0.35	600	185	25.4	4100
			700	215
			800	250
			1000	310
