Type: HRW12-11~15(F)/100, HRW12-11~15(F)/200
Rated Voltage: 11~15KV
Rated Current: 100A, 200A
Breaking Current: 10KA, 12.5KA
Impulse Voltage: 110KV
Power frequency withstand voltage:45KV
Leakage distance: 480mm
Weight: 6KGS, 6.5KGS
Dimensions: 480x480x145mm
Type: HRW12-24~27/100, HRW12-24~27/200
Rated Voltage: 24~27KV
Rated Current: 100A, 200A
Breaking Current: 10KA, 12.5KA
Impulse Voltage: 150KV
Power frequency withstand voltage: 70KV
Leakage distance: 660mm
Weight: 6KGS, 6.5KGS
Dimensions: 520x370x135mm
Type: HRW12-24~27(F)/100, HRW12-24~27(F)/200
Rated Voltage: 24~27KV
Rated Current: 100A, 200A
Breaking Current: 10KA, 12.5KA
Impulse Voltage: 150KV
Power frequency withstand voltage: 70KV
Leakage distance: 660mm
Weight: 6KGS, 6.5KGS
Dimensions: 510x400x145mm
Type: HRW12-33~36(F)/100, HRW12-33~36(F)/200
Rated Voltage: 33~36KV
Rated Current: 100A, 200A
Breaking Current: 10KA, 12.5KA
Impulse Voltage: 195KV
Power frequency withstand voltage: 85KV
Leakage distance: 1080mm
Weight: 6.5KGS,7KGS
Dimensions: 670x380x135mm
Type: HRW12-33~36/100, HRW12-33~36/200
Rated Voltage: 33~36KV
Rated Current: 100A, 200A
Breaking Current: 10KA, 12.5KA
Impulse Voltage: 195KV
Power frequency withstand voltage: 85KV
Leakage distance: 825mm
Weight: 6.5KGS,7KGS
Dimensions: 615x400x145mm
