Description:
The wire clamp is used to clamp the unrolled wire or ground wire after the wire is released or tightened to complete the related work on the line. According to the purpose of the cable clamp, there are wire clamp, ground wire clamp, optical cable clamp and wire rope clamp. Mainly used for clamping steel strand, traction wire rope and aluminum alloy wire.
Technical principle:
After the wire clamp clamps the ground wire, tension is applied to the pull ring, the sliding shaft of the pull ring slides in the body wire groove, driving the connecting plate, and the movable jaw seat rotates accordingly. Since the other end of the movable jaw seat is firmly hinged with the jaw, the movable jaw is forced to press down along the pin axis when rotating, and the cable is pressed on the fixed jaw seat. The greater the tension on the pull ring, the greater the downward pressure on the moving jaw, so as to ensure that the ground wire is tightly clamped by the moving jaw and the fixed jaw.
Structure composition:
Laifu pliers are mainly composed of movable jaw base, connecting plate, pull ring, fixed jaw (lower jaw), movable jaw (upper jaw), body and other components. Strengthening the hook can improve the overall force condition of the clamp while drilling, making the clamp while drilling safer and more reliable.
Aluminum alloy insulated wire grip
Aluminum alloy insulated wire clamp is mainly used to clamp the wire with insulating layer on the outside.
Method of use:
Clamp the insulated wire, adjust the sag, tighten and secure.
Features:
Using high-strength aluminum alloy material, light weight does not damage the insulation layer.
Data Sheet
Product Model | Applicable wire LJ/LGJ | Rated load KN | ultimate load KN | Conductor diameter mm | Weight kg |
SLK-1 | 25-70 | 10 | 20 | 13.8-17.8 | 1.6 |
SLK-2 | 95-120 | 15 | 30 | 19.6-21 | 2.4 |
SLK-3 | 150-240 | 20 | 40 | 22.6-26.4 | 2.8 |
SLK-4 | 300-400 | 25 | 50 | 27.4-32 | 3. |
