Aluminum XHHW-2 Power Cable Low Friction 600V1000V

Aluminum XHHW-2 Power Cable Low Friction 600V1000V

Low Friction type XHHW-2 is primarily used in house construction, conduit, or recognized raceways for services, feeders, and branch circuit wiring in wet or dry locations, at temperaturesnot to exceed 90℃.

Inquiry Contact us

Like this product? Share with friends:

Product Introduction

Desciption

Application:

Voltage rating is 600V/1000V.

This product is designed to be installed without the application of pulling lubricant.

Construction:

Conductor: Compact stranded AA-8000 series aluminum conductor material per ASTM B800, ASTM B801, ASTM B836, ASTM B901(Single Input Wire), as applicable.

Insulation:

The insulation is a low coefficient of friction, abrasion, moisture, and heat resistant thermoest cross-linked polyethylene.

Stocking most sizes in Black, Red, Blue, White, Green, Brown, Orange, Yellow, and Gray.

Standard:

UL 44, UL 1581, UL 2556

Federal specifications A-A-59544 and the requirements of the NEC

Federal specification JC-30B NEC

ANSI/NEMA WC 70-2009 ICEA S-95-658-2009

CT Rated-Sizes 1/0 AWG and larger are rated for Cable Tray use.

Sunlight Resistant in all color sizes 6AWG and larger.

Basic Flame Rated(FT2) for sizes 6AWG and larger.

RoHS compliant.
